    COP32 COP34 Mining Drilling Tools DHD Bit

    Ask Lasest Price
    Brand Name : New Diamond
    Model Number : COP32 COP34 COP44 COP54 COP64 COP84
    Price : 70-2000usd
    Payment Terms : T/T, Western Union
    Supply Ability : 100000pcs/month
    Delivery Time : 2-4weeks
    • Product Details
    • Company Profile

    COP32 COP34 Mining Drilling Tools DHD Bit

    COP32 COP34 COP44 COP54 COP64 COP84 Mineria Drilling Tools DHD Bit

    1.The longer life of the drill
    the alloy material, with longer using life which better than the similar products.
    2.High Drilling Efficiency
    the drill buttons is wear-resistant, so that the drill can always keep sharp, thus greatly improving the speed of the drilling.
    3.The drilling speed is stable
    the bit is scraped and cut to break the rock.
    4.Good Performance
    the New Diamond bit has strong wear resistance, good diameter protection and can make the cutting teeth be used efficiently.
    5.The use of a wide range
    the practice proves that the bit is suitable for carbonate rock, limestone, chalk, clay rock, siltstone, sandstone and other soft and hard (9 - grade drillability of rock, hard rock drilling), compared with normal bit, especially drilling in 6-8 grade rock the effect is particularly significant.
    6. Item number includes:
    COP32, IR3.5/COP34, DHD340/COP44, DHD350R/COP54,
    DHD360/COP64, DHD380/COP84, DHD1120...

    Specifications


    DHDHead shape

    Diameter

    (mm)

    Number of ventsNO X button diamterweight (KG)
    ToothedGaugeFront

    DHD3.5/ND35

    Flat Face Bit902Round Button+Ballistic Button6XØ145XØ124.7
    Flat Face Bit952Round Button+Ballistic Button6XØ145XØ124.8
    Flat Face Bit1002Round Button+Ballistic Button6XØ145XØ124.9
    Flat Face Bit1082Round Button+Ballistic Button8XØ135XØ125.4
    We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

    DHD seriesHead shape

    Diameter

    mm

    Number of ventsButton qty.pcs*dia.mmweight (KG)
    Button TypeGaugeFront
    DHD340/COP44/ND45Concave Face1082Spherical7XØ166XØ147.85
    Flat Face1152Spherical7XØ166XØ148.22
    Concave Face1272Spherical8XØ164XØ14+3XØ138.88
    Concave Face1302Spherical8XØ164XØ14+3XØ139.15
    We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

    DHD seriesHead shape

    Diameter

    mm

    Number of ventsButton qty.pcs*dia.mmweight (KG)
    Button TypeGaugeFront
    DHD350/COP54/ND55Concave Face1402Spherical7XØ184XØ15+3XØ1415.8
    Concave Face1462Spherical8XØ188XØ1416.5
    Concave Face1522Spherical8XØ188XØ1417
    Concave Face1652Spherical8XØ184XØ16+4XØ1418.9
    Concave Face1782Spherical8XØ186XØ16+5XØ1420.4

    We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.


    DHD seriesHead shape

    Diameter

    mm

    Number of ventsButton qty.pcs*dia.mmweight (KG)
    Button TypeGaugeFront
    DHD360/COP64/ND65Concave Face1522Spherical8XØ184XØ16+4XØ15
    Flat Face1652Spherical8XØ188XØ1623
    Concave Face1712Spherical8XØ186XØ16+4XØ1524.4
    Concave Face1782Spherical8XØ186XØ16+5XØ1525.3
    Concave Face1902Spherical9XØ186XØ16+5XØ1526.5
    Concave Face2032Spherical10XØ188XØ16+6XØ1529.7
    We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

    DHD seriesHead shapeDiameter
    mm
    Number of ventsButton qty.pcs*dia.mmweight (KG)
    Button TypeGaugeFront
    DHD380/COP84/ND85Concave Face2032Spherical10XØ184XØ18+10XØ1641.3
    Concave Face2162Spherical10XØ184XØ18+10XØ1645
    Concave Face2302Spherical12XØ1812XØ18+6XØ1647.8
    Concave Face2352Spherical12XØ1812XØ18+6XØ1648.4
    Concave Face2542Spherical12XØ1812XØ18+6XØ1655.3
    We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

    DHD seriesHead shape

    Diameter

    mm

    Number of ventsNO X button diamterweight (KG)
    ToothedGaugeFront
    DHD1120Convex concave3504Round Button16XØ2032XØ18+13XØ16-
    Convex concave4004Round Button16XØ2060XØ18+8XØ16-
    Convex concave5004Round Button24XØ2090XØ18-
    We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

    COP32 COP34 Mining Drilling Tools DHD Bit

    DHD3.5/ND35

    COP32 COP34 Mining Drilling Tools DHD Bit


    DHD340/COP44/ND45

    COP32 COP34 Mining Drilling Tools DHD Bit


    DHD350/COP54/ND55

    COP32 COP34 Mining Drilling Tools DHD Bit


    DHD360/COP64/ND65

    COP32 COP34 Mining Drilling Tools DHD Bit
